Name: BC32 Automated Blood Culture System | Rapid Microbial Detection
SKU: 1254
Availability: InStock

BC32 Automated Blood Culture System | Rapid Microbial Detection

Advanced Rapid Microbial Detection System

32-Bottle Capacity: Compact design optimized for small to mid-sized laboratories and specialized clinics.
Continuous Monitoring: Automated scanning every 10 minutes ensures the fastest possible “Time to Detection” (TTD).
Non-Invasive Technology: Colorimetric detection eliminates the risk of cross-contamination and manual handling errors.
Advanced Resin Media: Integrated antibiotic neutralization system ensures high recovery rates for patients already on therapy.
Smart Diagnostics: Real-time growth curves and multi-mode alarms (Audio, Visual, Color) for positive bottles.
Full Integration: Bidirectional LIS/HIS connectivity for seamless patient data and result management.

Description

BC32 Automated Blood Culture System: Precision Sepsis Management

In the fight against bloodstream infections, speed is the most critical factor. The BC32 Automated Blood Culture System is a sophisticated microbial detection platform designed to provide a stable, controlled environment for the rapid recovery of bacteria and fungi from blood and sterile body fluids (SBF).

[Image: Real-time Growth Curve and BC32 Interface]

Innovative Detection & High-Sensitivity Recovery

The BC32 utilizes advanced Colorimetric Detection Technology. This non-invasive method monitors the CO2 production of growing microorganisms within each bottle independently. By scanning every position every 10 minutes, the system captures the earliest signs of microbial metabolism, often providing positive results within 4 to 24 hours.

Key Features & Technical Advantages

Modular & Expandable Design: The BC32’s compact footprint is ideal for labs with limited space, yet it offers the same high-end algorithms found in larger scale models (BC64/BC128).
Superior Resin-Based Media: Our culture bottles utilize macroporous resin to neutralize a wide spectrum of antibiotics, significantly improving the recovery of fastidious organisms like Haemophilus and Neisseria.
User-Oriented Workflow: The “Scan-Load” workflow reduces hands-on time. Simply scan the barcode, and the system automatically assigns the bottle to a designated green-lit cell.
Reliable Stability: Features high-precision temperature control (35°C ± 1.5°C) and automated vibration/agitation to promote optimal microbial growth.

Technical Specifications Table

Feature	Technical Specification
Bottle Capacity	32 Culture Bottles (Simultaneous)
Detection Principle	Colorimetric (Non-invasive monitoring)
Scanning Frequency	Automatic every 10 minutes
Sample Types	Whole Blood and Sterile Body Fluids (SBF)
Dimensions	580mm × 440mm × 440mm
Weight	30 Kg (Benchtop design)
Positive Result Time	4 – 24 hours (Average), up to 72 hours for fastidious
Connectivity	RS-232, Ethernet (Full LIS/HIS Support)

High-Performance Blood Culture Bottles

To ensure the best results with the BC32, we provide a full range of specialized culture media:

Aerobic Culture Bottles (Adult/Pediatric): Optimized for the recovery of aerobic bacteria and fungi.
Anaerobic Culture Bottles: Designed with a reduced environment for the growth of obligate anaerobes.
L-Form Culture Bottles: Specialized media for the recovery of cell-wall-deficient bacteria.
Shatter-Resistant Design: Multilayer plastic bottles maximize lab safety by reducing biohazard exposure and disposal costs.
